• Commercial and Residential Use
• Multi size door closer
• Adjustable spring power
• Tri-packed
• Two separate regulating valves for adjustable closing and latching speeds.
• Standard Adjustable Back-Check and Delay Action Function
• Back check controlled by separate regulating valve
• Delay action controlled by separate regulating valve
• Precision heavy duty rack (piston) and pinion gear
• Factory tested to meet or exceed ANSI standard 156.4
• Non-sized closer with spring power adjustable from size 2 through 4
• Dual valve, closing and latching speed controlled by two separate regulating valves
• Needle bearing application for smooth operation
• Rack and pinion operation contained in a high tensile precision cast aluminum housing for the highest quality
• High quality anti-freeze hydraulic fluid for high lubricity and constant lubrication, suitable for exterior environment (temperature -30C to 40C; -22F to 104F)
• Available in Black, Silver, and Bronze (Choose your finish color above)

Specifications:

• Length of Closer Body: 9 3/4" (248 mm)
• Horizontal Mounting Holes: 9 1/16" (230 mm)
• Vertical Mounting Holes: 3/4" (19 mm)
• Height of Closer Body: 1 21/32" (42 mm)
• Projection From Door: 2 3/64" (52 mm)
• Suitable for Door Weight: 55 - 187 lbs (25 - 85 kg)

Door Closer Glossary Terms

Delayed Action
This feature performs like its name suggests, delays the door's closing speed so pedestrians, especially elderly or disabled, can have enough time to fully exit. The reduced closing time kicks in at any point beyond the open 70 degree angle and is helpful in a variety of environments like hospitals, offices, restaurants and so on. Feature also benefits those who utilize/push catering trays, office technology/equipment, gurney transportation, as well as assist delivery personal, wheel chair bound and other persons with disabilities.

Back Check
This feature can be used to sense and prevent the door closer from over extending and hitting an adjacent wall. It also reacts against wind, working to prevent the door from swinging out of control.

Latch Speed
Controls (often reduces) the closing speed of the final 10 to 15 degrees of the door. It should help the door close completely and effectively without slamming shut.

Non-Sized
Unit can be adjusted in the field to adapt to the size of the door and its closure needs.

Rack and Pinion
A pair of gears contained inside the door closer which enables consistent and smooth control throughout the closing cycle.

Tri-packed
Unit comes with proper brackets and installation hardware to be used as "regular/standard", "top jamb" or "parallel arm" applications. Universal application.

ANSI/BHMA
ANSI stands for the American National Standards Institute and BHMA (Builders Hardware Manufacturers Association). BHMA is the only U.S. accredited to determine criteria for the performance and safety of certain building products. They are assigned number/grading standards based on level of performance and durability.
