PanicExitPro.com is designed to provide an easy solution for commercial door access and crash bar exiting. We aim to make a Pro out of even the first time installer. We supply easily installed surface mount rim style panic exit bars that can be installed with very little expertise. Some considerations to be made when choosing your panic exit bar:

Single door panic exit installation on a glass door or narrow stile door:
Although the measurements on the panic bars may seem to fit the stile of your door, (a stile is the vertical area on the sides of the door that you are going to use for mounting commercial door hardware) standard one point latch bars have some complications when using outside trim or with glass doors. Outside trim increases the width of the stile needed to approximately 5 inches. the 2000 series panic exit bar has a special lever handle made for narrow stiles. Also with glass doors the aesthetics of what is seen through the door should be considered. With a standard panic exit bar the rear is not meant to be seen and would not be pleasing to see through the glass.

Dual door panic exit bar installation when doors overlap:

The number one instinct when equipping a dual door with panic exit bars is to put top and bottom 2 point latch vertical rod panic exit bars on each door. However if there is an overlap this would restrict exiting to a single door. Check out our video above for a demonstration on why to pair a side latch 1 point crash bar with a 2 point crash bar.

Access from the exterior:
Panic exit bars are designed the same in which you will always have a manual exit from the building, that choice is easy. However what is not as easy to decide if and how to allow access from the exterior. Depending on the purpose of the door you may decide to not have any door trim on the outside. If the door is not a heavily used exterior door you may use a crash bar with cylinder lock access and put a dummy pull handle on the outside. This would result in key access only and automatic locking as soon as the key is removed from the door. If the door is heavily used outside trim such as knob or lever handles can be used. In this case the handle would be locked or unlocked and general access can be allowed. Lastly for higher security properties that must allow general access electronic access can be paired with all of the surface mount panic exit bars. This has nearly unlimited variations of access possibilities.

Panic Bars
• Single Door Setup
• Door minimum width: 25"
• Push pad: Semi-length
• Latchbolt: 1/2" stainless steel
• Deadlocking latch bolt: 5/8" stainless steel
• Finish: Painted Finish or Stainless Steel

• Includes strikes (latching devices)
•
Includes cylinder lock and a pair of keys
• Works with Sentry Safety Handles ONLY
UL Certified Allen Key Dogging Feature Cylinder Release Key
$151.03
$100.98
Sentry Safety Hardware
• Dual Door Setup
• Door minimum width: 25"
• Push pad: Semi-length
• Latchbolt: 1/2" stainless steel
• Deadlocking latch bolt: 5/8" stainless steel
• Finish: Stainless Steel or Painted

• Includes strikes (latching devices)
• Includes stainless steel vertical rods
Note: This is an exit only panic bar
UL Certified Allen Key Dogging Feature
$160.14
$135.14
Sentry Safety Hardware
• Single Door Setup
• Bar Length: 28" or 36"
• Single Point Side Latch
• Door minimum width: 8"
• Door maximum width: 38.25"
• Finish: Stainless Steel

• Commanded for all types of doors
• Fits a left-hand or right-hand door
• Works with Sentry Safety Handles ONLY
$87.49
$67.49
Sentry Safety Hardware
• Dual Door Setup
• Bar Length: 28" or 36"
• Door minimum width: 8"
• Door maximum width: 38.25"
• Finish: Stainless Steel

• Narrow Stile Two Point Latch Rim
• Commanded for all types of doors
• Fits a left-hand or right-hand door

• Includes strikes (latching devices)
• Includes vertical rods
Note: Used for Exit purposes only.

$135.00
$125.00
Sentry Safety Hardware
• Single Door Setup
• Bar Length: 36"
• Door minimum width: 8"
• Door maximum width: 38.25"
• Finish: Stainless Steel

• Three-Point Latching Panic Device
• Commanded for all types of doors
• Fits a left-hand or right-hand door

$150.00
Sentry Safety Hardware
• Fits a left-hand or right-hand door
• Single Door Setup
• Bar Length: 40"
• Door minimum width: 25"
• Push pad: Semi-length
• Latchbolt: 11/16" stainless steel
• Finish: Painted Finish or Stainless Steel

• Includes strikes (latching devices)
• Includes cylinder lock and a pair of keys

• Works with Sentry Safety Handles ONLY
Knob Dogging Feature Cylinder Release
$75.98
Sentry Safety Hardware
• Dual Door Setup
• Bar Length: 40"
• Door minimum width: 25"
• Push pad: Semi-length
• Latchbolt: 1/2" stainless steel
• Deadlocking latch bolt: 5/8" stainless steel
• Finish: Painted Finish or Stainless Steel

• Includes strikes (latching devices)
• Includes stainless steel vertical rods

$104.32
Sentry Safety Hardware
• Single or Dual Door Setup
• Door minimum width: 25"
• 3 Point Latch Rim
• Push pad: Semi-length
• Latchbolt: 1/2" stainless steel
• Finish: Aluminum Sprayed
• Includes strikes (latching devices)
• Includes stainless steel vertical rods
• Includes cylinder lock and key
Knob Dogging Security Cylinder Release Key
$149.00
Sentry Safety Hardware
• Single Door Setup
• Door minimum width: none
• Door maximum width: 40"
• Width of bracket to attach to frame: 1 1/2"
• Finish: Red or Stainless Steel finish

• Recommended for doors with glass inserts
• Fits a left-hand or right-hand door

• Include strikes (latching devices)
• Works with Sentry Safety Handles ONLY

$64.99
Sentry Safety Hardware
• Dual Door Setup
• Two Point Latch Rim
• Door minimum width: none
• Door maximum width: 40"
• Width of bracket to attach to frame: 1 1/2"
• Finish: Red or Stainless Steel finish

• Recommended for doors with glass inserts
• Fits a left-hand or right-hand door

• Includes strikes (latching devices)
• Includes a vertical steel rod

$104.58
Sentry Safety Hardware
• Single Door Setup
• Door minimum width: 25"
• Push pad: Semi-length
• Latch bolt: 5/8" stainless steel
• Deadlock latch bolt: 5/8" stainless steel
• Finish: Painted or Stainless Steel
• Includes strikes (latching devices)
• Includes cylinder lock and key
• Works with Sentry Safety Handles ONLY
C-UL Certified ANSI/BHMA Grade 1 Standards3 Hour Fire ResistanceCylinder Release Key
$114.99
Sentry Safety Hardware
• Dual Door Setup
• Door minimum width: 25"
• Push pad: Semi-length
• Latch bolt: 5/8" stainless steel
• Deadlock latch bolt: 5/8" stainless steel
• Finish: Painted or Stainless Steel
• Includes strikes (latching devices)
• Includes stainless steel vertical rods
C-UL Certified ANSI/BHMA Grade 1 Standards3 Hour Fire Resistance
$158.50
Sentry Safety Hardware
• Single Door Setup
• Door minimum width: 25"
• Push pad: Full-length
• Latch bolt: 5/8" stainless steel
• Deadlock latch bolt: 5/8" stainless steel
• Finish: Painted or Stainless Steel
• Includes strikes (latching devices)
• Includes cylinder lock and a pair of keys
• Works with Sentry Safety Handles ONLY
C-UL Certified ANSI/BHMA Grade 1 Standards3 Hour Fire ResistanceCylinder Release Key
$118.00
Sentry Safety Hardware
• Dual Door Setup
• Door minimum width: 25"
• Push pad: Full-length
• Latch bolt: 5/8" stainless steel
• Deadlock latch bolt: 5/8" stainless steel
• Finish: Painted or Stainless Steel
• Includes strikes (latching devices)
C-UL Certified ANSI/BHMA Grade 1 StandardsFire Rated
$186.70
Sentry Safety Hardware
• Single Door Setup
• Door minimum width: 30 7/8"
• Push pad: Semi-length
• Latch bolt: 5/8" stainless steel
• Deadlocking latch bolt: 5/8" stainless steel
• Finish: Stainless steel

• Includes strikes (latching devices)
• Includes cylinder lock and a pair of keys
• Works with Sentry Safety Handles ONLY
Alarm Feature Cylinder Release Key
$181.50
Sentry Safety Hardware
• Dual Door Setup
• Door minimum width: 30 7/8"
• Push pad: Semi-length
• Latch bolt: 5/8" stainless steel
• Deadlocking latch bolt: 5/8" stainless steel
• Finish: Stainless steel

• Includes strikes (latching devices)
• Includes cylinder lock and a pair of keys
Alarm Feature Cylinder Release Key
$195.00
Sentry Safety Hardware
• Single Door Setup
• Door minimum width: 34 1/2"
• Length: 34 1/2"
• Deadlock latch bolt: 5/8" stainless steel
• Finish: Satin Silver Painted Finish
• Includes a dual micro switch output
• Works with Sentry Safety Handles ONLY
Security
$132.00
Sentry Safety Hardware
  • Field selectable nuisance delay
  • Field selectable 15 or 30 second exit delay
  • Emergency signal input
  • Key reset and bypass
  • Works with Sentry Safety Handles ONLY
  • $177.10
    Sentry Safety Hardware
    • Single Door Setup
    • Bar Length: 36" (48" upon request)
    • Handling: Reversible/Non-handed
    • Door Width: 36" - can be field sized to fit 30"
    • Finish Options: Aluminum or Stainless Steel
    • Stile: 4 1/4" minimum
    • Mounting Height: Recommended to install at 41" from finished floor to   enterline of push rail
    UL Certified Allen Key Dogging Grade-ANSI A156.3 Grade 2
    $164.35
    • Single Door Setup
    • Bar Length: 36"
    • Handling: Reversible/Non-handed
    • Door Width: 36" - can be field sized to fit 30"
    • Finish Options: Aluminum
    • Stile: 4 1/4" minimum
    • Mounting Height: Recommended to install at 41" from finished floor to   centerline of push rail
    ANSI/BHMA A156.3-2000 Grade 1C-UL Listed Fire Resistant
    $176.48
    • Single Door Setup
    • Bar Length: 42"
    • Handling: Reversible/Non-handed
    • Door Width: 48"
    • Finish Options: Aluminum or Stainless Steel
    • Stile: 4 1/4" minimum
    • Mounting Height: Recommended to install at 41" from finished floor to centerline of   push rail
    ANSI/BHMA A156.3-2000 Grade 1C-UL Listed Fire Resistant
    $175.48
    • Single Door Setup
    • Bar Length: 36"
    • Handling: Non-handed
    • Door Thickness: 1 3/4" - 2 1/4"
    • Finish Options: Aluminum or Black
    • Stile: 3" or greater stile
    • Deadlock Latchbolt: Stainless steel 3/4" deadlocking Pullman-type latch   bolt
    Hex Key Dogging
    $297.00
    • Single Door Setup
    • Bar Length: 36"
    • Handling: Non-handed
    • Door Thickness: 1 3/4" - 2 1/4"
    • Finish Options: Aluminum
    • Stile: 3" or greater stile
    • Deadlock Latchbolt: Stainless steel 3/4" deadlocking Pullman-type latch   bolt
     Hex Key Dogging Alarm Function Ansi1 ADA Compliant
    $416.08
    • Single Door Setup
    • Bar Length: 36"
    • Handling: Non-handed
    • Door Thickness: 1 3/4" - 2 1/4"
    • Weatherized - designed for outdoor or wet environments
    • Stile: 3" or greater stile
    • Deadlock Latchbolt: Stainless steel 3/4" deadlocking Pullman-type latch   bolt
     Hex Key Dogging Alarm Function ANSI/BHMA Grade 1 ADA Compliant
    $579.58
    $559.58
    • Single and Double Door Setup
    • Device Length: 3'
    • Single Point Side Latch Rim
    • Door minimum width: 24-3/4"
    • Door maximum width: 36"
    • Door Stile minimum width: 4-3/4"
    • Finish: Sprayed aluminum
    • Strike: 299 - Dull Black
    • Latchbolt: 3/4"
    • Deadlock latchbolt: 3/4"
    Exit Only Function (outside trim not included)
    UL Certified Allen Key Dogging Feature
    $415.00
    $320.43
    • Single and Double Door Setup
    • Device Length: 3'
    • Door Stile minimum width: 1-3/4"
    • Single Point Side Latch Rim
    • Finish: Anodized Aluminum
    • Strike: 1439 - Dull Black Finish
    • Latchbolt: 3/4"
    • Deadlock latchbolt: 3/4"
    Exit Only Function (outside trim not included)
    UL Certified Hex Key Dogging ANSI
    $1,113.02
    • Single and Double Door Setup
    • Device Length: 3'
    • Door minimum width: 2' 4"
    • Door maximum width: 3'
    • Finish: Anodized Aluminum
    • Strike: 299 - Dull Black Finish
    • Latchbolt: 3/4"
    • Deadlock latchbolt: 3/4"
    Exit Only Function (outside trim not included)
    UL Certified Hex Key Dogging ANSI
    $1,135.00
